Cooper Bussmann BG3013SQ 3-pole Din Rail Fuse Block 15A 600V

Product Description

The COOPER BUSSMANN BG3013SQ is a 3-pole DIN rail mount fuse block rated for 15 amps at 600 VAC/VDC. It accepts 10 to 14 AWG wire via screw terminals with quick-connect capability and is compatible with Class G fuses. The block measures 3 inches long by 2.38 inches wide by 1.22 inches high and weighs 0.22 pounds. It carries UL Recognition under Guide IZLT2 File E14853 and CSA Certification under C22.2 No. 39 Class 6225-01 File 47235, making it suitable for use in listed electrical enclosures and control panels. Electricians and panel builders rely on this block for organized, serviceable overcurrent protection in industrial and commercial wiring applications.

This fuse block is intended for use in electrical control panels, distribution boards, and industrial enclosures where DIN rail mounting is the standard. The 3-pole configuration allows three separate circuits to be fused from a single compact assembly. Its 600 VAC/VDC rating covers a wide range of AC and DC control and power circuits commonly found in commercial building systems, motor control centers, and equipment panels. The screw-with-quick-connect wire termination supports fast, reliable field wiring for electricians working under time constraints.

Key Features

• 3-pole configuration for fusing three independent circuits in one compact block
• Rated 15 amps at 600 VAC/VDC for broad AC and DC circuit coverage
• Accepts 10 to 14 AWG wire via screw terminals with quick-connect option
• Compatible with Class G fuses
• DIN rail mount design for standard panel installation
• UL Recognized and CSA Certified for use in listed assemblies

Compatibility

Designed as a DIN rail mount replacement or new-installation fuse block compatible with Class G fuses in standard electrical enclosures and control panels rated up to 600 VAC/VDC.

Installation Notes

Installation should be performed by a licensed electrician in accordance with NEC requirements and applicable local codes. De-energize and lock out the panel before mounting or wiring the fuse block. Secure the block firmly on the DIN rail before making wire terminations, and verify that wire gauge and fuse class selections match the circuit requirements prior to energizing.
