COOPER BUSSMAN ABC-1-R Fast-Acting Fuse 1A

Product Description

The COOPER BUSSMAN ABC-1-R is a 1A fast-acting fuse, suitable for electronic circuits. This fuse is part of the Eaton AGC series and is constructed from a glass tube with nickel-plated brass end caps. It is designed for easy installation with ferrule end connections.

• Fast-acting fuse ideal for electronic circuits
• High-quality glass tube construction
• Ferrule end x ferrule end connections for simple wiring

Product Highlights

Product Information

Standard Information

• Product Name: Eaton Bussmann series AGC fast-acting glass tube fuse
• Catalog Number: AGC-1-R

Technical Specifications

• UPC: 051712654814
• Product Length: 1.25 inches
• Product Height: 0.25 inches
• Product Width: 0.25 inches
• Amperage Rating: 1 A
• Fuse Indicator: Non-indicating
• Connection: Ferrule end x ferrule end
• Response Time: 60 min at 135%, 120 sec at 200%
• Material: Glass tube with nickel-plated brass end cap
• Voltage Rating: 250 Vac, 32 Vdc (self certified)
• Type: Electronic
• Application: Electronic circuits
• Compliances: CE Marked, RoHS Compliant
