Rheem 47-23610-19 Limit Switch - Auto Reset (Flanged Airstream) 230V 25A

Product Description

The Rheem 47-23610-19 is an auto reset limit control switch designed to operate at 230 volts and a maximum current of twenty-five amps. This switch is used in HVAC systems to ensure that fans or other components function properly when specific temperature conditions are met. Primarily employed in flanged airstream applications, this switch provides reliable operation.

• Auto reset functionality for consistent performance
• Flanged mounting design for straightforward installation
• Durable construction for long operational life

Product Highlights

This limit switch offers a dependable means of regulating airflow in HVAC systems. Its automatic reset feature minimizes manual intervention, making it ideal for routine HVAC applications.

Product Information

Standard Information

• Brand: Rheem
• MPN: 47-23610-19

Technical Specifications

• Switch Type: SPST
• Contact Orientation: Normally Closed
• Open Temperature: 165 degrees F
• Close Temperature: 145 degrees F
• Amperage Rating: 25A
• Voltage Rating: 230V
• Connection Type: 1/4 inch Quick Connect
• Mounting Depth: 25/32 inch
• Color Code: Yellow/White
