Continental Contitech 20250462 Synchronous Belt 8M

Product Description

The CONTINENTAL CONTITECH 20250462 is a synchronous timing belt designed for power transmission applications requiring precise, slip-free motion control. Built to 8M section standards with an 8 mm pitch and 100 teeth, this belt delivers consistent indexing and synchronization across a 800 mm pitch length. Constructed from rubber in a black finish, it operates reliably across a wide temperature range. The Falcon HTC series designation indicates a high-torque-capacity design suited for demanding drive systems. Licensed HVAC, mechanical, and industrial technicians install this type of belt in belt-driven equipment requiring exact timing between shafts.

This belt fits drive applications calling for an 8M section synchronous belt with a 36 mm width and 800 mm pitch length. It carries the belt number 8GTR-800-36, which is the standard industry cross-reference identifier for this specification. Typical installation scenarios include HVAC blower assemblies, pump drives, compressor drives, and other rotating equipment where synchronous power transmission is required. The 100-tooth count and 8 mm pitch make this belt a direct fit for pulleys and sprockets designed to the 8GTR series specification.

Key Features

• 8M section synchronous belt with 8 mm pitch for accurate timing and zero-slip power transfer
• 36 mm belt width rated for high-torque drive applications
• 100 teeth over an 800 mm pitch length for precise shaft synchronization
• Rubber construction handles operating temperatures from -22 degrees F to 210 degrees F
• Falcon HTC series design for high-torque-capacity drive systems
• Belt number 8GTR-800-36 for straightforward cross-reference and replacement sourcing

Compatibility

Designed as an OEM-style replacement synchronous belt for drive systems requiring an 8M section, 36 mm wide, 800 mm pitch length belt identified by belt number 8GTR-800-36.

Installation Notes

Synchronous belt replacement is typically performed by licensed mechanical or HVAC technicians. De-energize and lock out the drive system fully before removing the old belt or adjusting tensioner components. Do not force the belt over pulley flanges using tools that could nick or crack the tooth profile. After installation, verify proper tension and pulley alignment per the equipment manufacturer's service documentation before returning the unit to operation.
