Continental Contitech 20250460 Synchronous Belt 8M

Product Description

The CONTINENTAL CONTITECH 20250460 is a synchronous timing belt designed for precision power transmission in industrial and mechanical drive systems. Built to the 8M belt section standard, it features an 8 mm pitch and 100 teeth along an 800 mm outside pitch length, delivering positive engagement without slip. The belt is constructed from rubber in a black finish and carries the manufacturer belt number 8GTR-800-12, placing it in the Falcon HTC series. At 12 mm wide, it fits compact drive configurations where accurate timing and load transfer are required. Licensed HVAC, industrial, and mechanical technicians install these belts in equipment ranging from fan assemblies to pump drives.

This belt is suited for synchronous drive applications in both light industrial and commercial mechanical systems. The 8M section is a widely used metric timing belt standard, making this part applicable to conveyor drives, blower assemblies, and other equipment requiring consistent tooth engagement at defined center distances. It is rated for operating temperatures from -22 degrees F to 210 degrees F, which covers most indoor mechanical equipment environments. The Falcon HTC series designation indicates a high-torque-capacity construction within the 8M belt family.

Key Features

• 8M belt section with 8 mm pitch for positive, no-slip synchronous drive
• 100 teeth over an 800 mm outside pitch length
• 12 mm belt width for compact drive configurations
• Rubber construction rated from -22 degrees F to 210 degrees F
• Falcon HTC series for high-torque-capacity performance
• Belt number 8GTR-800-12 for direct cross-reference and replacement sourcing

Compatibility

Designed as an OEM-style replacement synchronous timing belt for 8M-section drive systems requiring a 12 mm wide, 800 mm pitch length belt with 100 teeth. Cross-references belt number 8GTR-800-12.

Installation Notes

Installation should be performed by a qualified mechanical or industrial technician. Always de-energize and lock out the drive system before removing or installing the belt. Do not force the belt over sheave flanges; adjust center distance to allow proper seating. Verify pulley alignment and tension per the equipment manufacturer's drive specifications before returning the system to service.
