Continental Contitech 20043106 Timing Belt 150L 40T

Product Description

The CONTINENTAL CONTITECH 20043106 is an L-series positive-drive timing belt designed for precision power transmission applications. It features a trapezoidal tooth profile with 40 teeth and a pitch length of 150.00 mm, corresponding to the 150L belt designation. The belt body is constructed from nylon with a fiberglass cord reinforcement, providing dimensional stability under load and resistance to elongation over time. This timing belt is installed by mechanical technicians and maintenance professionals in industrial, HVAC, and equipment-drive applications where synchronized motion and accurate speed ratios are required.

The 20043106 fits applications calling for an L-section positive-drive belt with a 15.00-inch internal length and 40-tooth count. L-series timing belts are commonly found in light-duty industrial machinery, blower drives, pump drives, and precision positioning equipment. This belt is suited for both OEM replacement and new installation in systems that specify the 150L belt number or an equivalent L-series trapezoidal-tooth drive belt.

Key Features

• L-series trapezoidal tooth profile for positive, slip-free power transmission
• 40-tooth count with 150.00 mm pitch length, designated as 150L
• Nylon belt material resists wear and handles moderate operating temperatures
• Fiberglass cord reinforcement limits stretch and maintains timing accuracy under load
• 15.00-inch internal belt length suits a wide range of standard L-section drive configurations

Compatibility

Designed as a direct replacement for applications specifying a 150L L-series positive-drive timing belt with a 40-tooth trapezoidal profile and 15.00-inch internal length.

Installation Notes

Timing belt replacement should be performed by a qualified mechanic or maintenance technician. Power down and lock out the equipment completely before removing the belt guard or tensioner. Avoid prying the belt over sprocket flanges, as this can damage cord reinforcement. Verify sprocket alignment and tension according to the equipment manufacturer specifications before returning the drive to service.
