Continental Contitech 20043073 Xl Timing Belt 130XL

Product Description

The CONTINENTAL CONTITECH 20043073 is an XL-series positive-drive timing belt designed for precision power transmission in mechanical drive systems. Built to the 130XL belt specification, it features 65 trapezoidal teeth and a nylon body with a fiberglass tension cord. The XL section designation indicates a 0.200-inch pitch standard, making this belt a direct fit in applications requiring accurate, slip-free synchronization between drive components. Installation is performed by mechanical maintenance technicians and industrial service professionals working on belt-driven equipment.

This timing belt suits light-duty and medium-duty synchronous drive applications found in industrial machinery, HVAC blower assemblies, pumping equipment, conveyor systems, and precision positioning drives. The 130XL designation is a recognized industry-standard belt number, making cross-referencing to existing equipment specifications straightforward. The XL series is commonly specified where exact timing between driver and driven shafts must be maintained without slippage.

Key Features

• 130XL belt number with 65 trapezoidal teeth for positive, no-slip synchronization
• Nylon belt body construction for wear resistance and dimensional stability
• Fiberglass tension cord provides high tensile strength with minimal stretch
• XL-series positive-drive style for accurate shaft-to-shaft timing
• 13.0-inch internal belt length supports a wide range of center-distance configurations

Compatibility

Designed as an OEM-style replacement or direct-fit timing belt for synchronous drive systems specifying the 130XL belt number in the XL series positive-drive standard.

Installation Notes

De-energize and lock out the drive system before removing the existing belt. Verify correct center distance and sprocket tooth count match the 130XL specification before installing the replacement belt. Do not pry the belt over sprocket flanges; relieve center distance by loosening the adjustment mechanism. Confirm proper belt tension according to the equipment manufacturer's service documentation after installation.
