Continental Contitech 20043049 Xl Timing Belt 95T

Product Description

The CONTINENTAL CONTITECH 20043049 is an XL-section synchronous timing belt designed for positive-drive power transmission applications. It carries 95 trapezoidal teeth on a 190XL belt number designation, with a pitch length of 190.00 mm and an internal length of 19.0 inches. The belt is constructed from nylon with a fiberglass cord reinforcement, which provides dimensional stability under load and resists elongation over service life. It is installed by mechanical technicians and maintenance professionals working on light-duty power transmission systems including conveyors, HVAC equipment drives, and precision machinery requiring accurate speed ratios.

This belt is suited for applications that require positive, slip-free synchronization between drive and driven shafts. XL-series belts are commonly found in residential and commercial HVAC blower assemblies, small conveyor systems, medical equipment, and industrial automation drives. The trapezoidal tooth profile mates with standard XL-pitch sprockets and pulleys. This belt is a direct-replacement style component for any application calling out a 190XL belt in the XL positive-drive series.

Key Features

• XL-section positive-drive timing belt for accurate, slip-free power transmission
• 95 trapezoidal teeth for precise indexing and synchronization
• Nylon construction resists wear and maintains tooth geometry under load
• Fiberglass cord reinforcement minimizes belt stretch and elongation
• 190XL belt number designation for straightforward cross-reference and replacement
• 190.00 mm pitch length with 19.0-inch internal length

Compatibility

Designed as an OEM-style replacement for XL-series positive-drive timing belt applications requiring a 190XL belt designation with standard XL-pitch sprockets and pulleys.

Installation Notes

Shut down and de-energize the drive system before removing the worn belt and inspecting the sprockets for wear or damage. Align drive and driven sprockets squarely before seating the replacement belt to avoid premature edge wear or tooth skip. No tools that alter belt tension beyond manufacturer sprocket center-distance specifications should be used. Belt replacement on HVAC blower drives typically falls within the scope of a licensed HVAC technician or qualified mechanical maintenance technician.
