Continental Contitech 20042830 Cogged V-belt 5L 25 in

Product Description

The CONTINENTAL CONTITECH 20042830 is a cogged fractional horsepower V-belt in the 5L section, with a 25-inch outside length and a 23.80-inch internal length. Built from high-traction rubber, the cogged construction reduces bending resistance and heat buildup, making it well suited for smaller horsepower drives where efficiency and belt life matter. It carries the belt number designation 5L250 and is rated for operation from -40 degrees C up to 140 degrees C, covering a broad range of service environments. This belt is a standard replacement component installed by HVAC technicians, equipment service professionals, and maintenance trades.

The 5L-section cogged V-belt sees frequent use in residential and light commercial HVAC systems, specifically in blower and fan drive applications. It also appears in agricultural equipment, compressors, and general-purpose machinery where fractional horsepower drives are standard. The cogged profile allows the belt to flex smoothly around smaller diameter sheaves, which is common in these compact drive configurations. Any application currently running a 5L250 belt is a direct candidate for this replacement.

Key Features

• Cogged design reduces heat buildup and improves flex life on small-diameter sheaves
• High-traction rubber construction provides reliable grip under load
• Abrasion-resistant compound extends service life in dusty or debris-prone environments
• Ozone-resistant formulation resists surface cracking from environmental exposure
• Wide temperature range: -40 degrees C minimum to 140 degrees C maximum
• Belt number 5L250 for straightforward cross-reference and replacement ordering

Compatibility

Designed as a direct replacement for any drive application currently using a 5L250 fractional horsepower V-belt with a 5L section profile and 25-inch outside length.

Installation Notes

V-belt replacement is typically performed by HVAC technicians or general mechanical maintenance trades. Always de-energize and lock out the equipment before removing belt guards or accessing the drive assembly. Never pry a belt over a sheave under tension; loosen the motor mount or idler to create slack before installation. After seating the belt, adjust drive tension to manufacturer specifications and verify sheave alignment before restoring power.
