Continental Contitech 20042774 Cogged V-belt 4L 46 in

Product Description

The CONTINENTAL CONTITECH 20042774 is a fractional horsepower cogged V-belt designed for light-duty power transmission applications in HVAC, refrigeration, and general mechanical equipment. Manufactured from high traction rubber, this 4L-section belt measures 46 inches in outside length and 45 inches in internal length. The cogged construction reduces heat buildup and flexing resistance, making it well-suited for smaller-diameter sheaves found in blower and fan drive assemblies. HVAC technicians and mechanical service professionals are the primary installers. The belt carries belt number 4L460 and is rated for continuous operation across a wide temperature range.

This belt fits fractional horsepower drive applications commonly found in residential and light commercial HVAC equipment, including evaporator blower assemblies, condenser fan drives, and other belt-driven auxiliary equipment. It is also used in agricultural, industrial, and commercial machinery where a standard 4L-section drive belt is specified. The 4L460 designation is a widely recognized industry cross-reference for service and replacement sourcing. Always verify sheave groove profile and center-to-center distance before installation to confirm proper fitment.

Key Features

• Cogged belt design reduces bending stress and improves flexibility on small-diameter sheaves
• High traction rubber construction provides reliable grip and power transfer
• Abrasion resistant and ozone resistant for extended service life in outdoor and mechanical environments
• Rated for operation from -40 degrees F to 284 degrees F (140 degrees C maximum working temperature)
• Belt number 4L460 is a standard fractional horsepower industry designation for easy cross-referencing

Compatibility

Designed as an OEM-style replacement for fractional horsepower belt-driven equipment requiring a 4L-section cogged V-belt with a 46-inch outside length. Verify sheave section profile and drive center distance prior to installation.

Installation Notes

Belt replacement should be performed by a qualified HVAC technician or mechanical service professional. Disconnect and lock out all power to the unit before removing the belt guard or accessing the drive assembly. Never pry a belt over a sheave with a screwdriver or bar; always reduce center-to-center distance to allow proper belt seating. After installation, verify correct tension and sheave alignment before returning the unit to service.
