Continental Contitech 20042694 3L Cogged V-belt 26in

Product Description

The CONTINENTAL CONTITECH 20042694 is a cogged fractional horsepower V-belt designed for light-duty power transmission applications. Manufactured from high traction rubber, this belt carries a 3L cross-section profile and measures 26 inches in outside length with an internal length of 25.30 inches. The cogged construction reduces bending resistance, which improves flexibility and helps the belt run cooler on smaller-diameter pulleys. It is also rated for abrasion resistance and ozone resistance, making it suitable for demanding service environments. HVAC technicians, equipment service professionals, and maintenance trades install this type of belt on fractional horsepower drives across a wide range of residential and light commercial applications.

The 3L260 belt is commonly found on fractional horsepower drives in residential and light commercial HVAC equipment, small air handlers, exhaust fans, and general-purpose machinery that uses narrow V-belt sheaves in the 3L cross-section. Its operating temperature range spans from -40 degrees C to 140 degrees C, allowing use in both cold-weather startup conditions and high-ambient environments typical of equipment rooms and rooftop installations. This belt ships as a single unit and is also referenced by its belt designation 3L260.

Key Features

• Cogged design reduces bending resistance for improved flexibility on small-diameter pulleys
• High traction rubber construction for reliable power transfer
• Abrasion resistant and ozone resistant for extended service life
• Wide operating temperature range: -40 degrees C to 140 degrees C
• 3L fractional horsepower cross-section with 26 inches outside length
• Belt designation 3L260 for cross-reference ordering

Compatibility

Designed as an OEM-style replacement for fractional horsepower drives using a 3L cross-section V-belt with a 26 inch outside length, also referenced as belt number 3L260.

Installation Notes

Installation should be performed by a qualified technician following proper lockout/tagout procedures to de-energize the equipment before servicing any belt drive. Never roll or force a belt onto a sheave using a pry bar, as this can damage the belt cords and reduce service life. Check sheave alignment and tension according to the equipment manufacturer's specifications before returning the unit to service.
