Continental Contitech 20042549 V-belt 5V 100 in

Product Description

The CONTINENTAL CONTITECH 20042549 is a 5V section V-belt designed for industrial and HVAC drive applications requiring reliable power transmission. Built from fiber reinforced Wingprene rubber in the HY-T Wedge Matchmaker Envelope style, this belt delivers oil resistance and dimensional stability under load. With a 100-inch outside length, it fits larger blower, fan, and compressor drive systems commonly serviced by HVAC technicians, millwrights, and mechanical contractors. The 5V cross-section is a wedge-style profile engineered for high-horsepower, matched-set drive configurations where belt slip and stretch must be minimized.

This belt is suited for commercial and industrial applications including rooftop unit blower drives, air handling unit fan drives, and general-purpose industrial machinery where 5V section drives are specified. The 100-inch outside length corresponds to belt designation 5V1000. It is sold individually and is appropriate for single or matched-set installations on drives requiring 5V cross-section geometry. Installation is typically performed by HVAC technicians or mechanical contractors servicing belt-driven air handling and refrigeration equipment.

Key Features

• 5V wedge section profile for high-horsepower drive applications
• 100-inch outside length — belt designation 5V1000
• Fiber reinforced Wingprene rubber construction for durability and flexibility
• Oil resistant — suitable for environments with incidental oil exposure
• HY-T Wedge Matchmaker Envelope style for use in matched-set drive systems
• Sold as a single belt with no minimum order quantity above one unit

Compatibility

Designed as an OEM-style replacement 5V section V-belt for commercial HVAC, air handling, and industrial fan or blower drives specifying a 5V1000 belt designation with a 100-inch outside length.

Installation Notes

Belt replacement is performed by licensed HVAC technicians or qualified mechanical contractors. Always de-energize and lock out the drive system before removing or installing belts. Adjust drive sheave centers to allow belt installation without forcing the belt over sheave grooves — never pry a belt into place. After installation, verify belt tension and alignment per the equipment manufacturer's specifications before returning the unit to service.
