Continental Contitech 20042163 V-belt Section B B195

Product Description

The CONTINENTAL CONTITECH 20042163 is a Section B V-belt designed for industrial and commercial drive applications. Built with Wingprene rubber-impregnated fabric, this belt delivers reliable power transmission across a wide operating temperature range of -40 degrees C to 140 degrees C. It carries a belt number of B195 and features an outside length of 198.0 inches with an internal length of 196.80 inches. The HY-T Matchmaker style is engineered for matched-set drive systems where belt-to-belt consistency is critical. This belt is typically installed by maintenance technicians and mechanical contractors on fan, pump, compressor, and blower drives.

This V-belt is suited for residential, commercial, and light industrial applications where Section B drives are specified. Common install scenarios include HVAC air handler fan drives, agricultural equipment, industrial conveyor systems, and pump drive assemblies. The B195 designation identifies this belt within standard banded and single-belt configurations. The Wingprene construction resists heat, oil, and wear, making it a dependable choice for systems that run continuously or under variable load conditions.

Key Features

• Section B profile with 198.0 inch outside length and 196.80 inch internal length
• Wingprene rubber-impregnated fabric construction for heat and oil resistance
• Wide operating temperature range: -40 degrees C to 140 degrees C
• HY-T Matchmaker style designed for use in matched-set drive configurations
• Belt number B195 for straightforward cross-reference and replacement identification

Compatibility

This belt is identified by belt number B195 and is designed as an OEM-style replacement for Section B V-belt drive applications where a 198.0 inch outside length is specified.

Installation Notes

V-belt replacement is typically performed by mechanical contractors or HVAC technicians. Always de-energize and lock out the drive motor before beginning belt removal or installation. Do not use tools to force the belt over sheave grooves — adjust the drive center distance to allow proper seating. After installation, verify belt tension and sheave alignment according to the equipment manufacturer's specifications before returning the system to service.
