Continental Contitech 20042158 V-belt Section B 176 in B173

Product Description

The CONTINENTAL CONTITECH 20042158 is a Section B V-belt designed for industrial and commercial power transmission applications. Built with Wingprene rubber-impregnated fabric construction, this belt delivers reliable flex and heat resistance across a wide temperature range, from -40 degrees C to 140 degrees C. It carries the belt designation B173, with an outside length of 176 inches and an internal length of 174.80 inches. The HY-T Matchmaker style designation indicates it is engineered for matched-set compatibility, making it suitable for multi-belt drive configurations. Installation is typically performed by HVAC technicians, millwrights, or mechanical contractors maintaining belt-driven equipment.

This V-belt is suited for residential and commercial HVAC systems, industrial fans, blowers, compressors, pumps, and other belt-driven rotating equipment requiring a Section B profile. The Section B cross-section is a standard industrial profile widely used in hvac air handlers, rooftop units, and centrifugal blower assemblies. The HY-T Matchmaker designation supports use in matched multi-belt drive applications where uniform belt length is critical for balanced load distribution.

Key Features

• Section B profile with 176-inch outside length and 174.80-inch internal length
• Wingprene rubber-impregnated fabric construction for durability and flex resistance
• Rated for operation from -40 degrees C to 140 degrees C
• HY-T Matchmaker style supports matched multi-belt drive set configurations
• Belt designation B173 for straightforward cross-reference and replacement identification

Compatibility

Designed as an OEM-style replacement Section B V-belt for belt-driven HVAC, blower, fan, and industrial drive systems requiring a 176-inch outside length belt with a standard B-section profile. Cross-references to belt number B173.

Installation Notes

Belt replacement should be performed by a qualified HVAC technician or mechanical contractor. De-energize and lock out the equipment fully before removing the drive guard or accessing the belt sheaves. Never pry a belt over a sheave with tools that could damage the belt cords or sheave groove. After installation, inspect sheave alignment and adjust drive tension according to the equipment manufacturer specifications before returning the unit to service.
