Continental Contitech 20042112 V-belt Section B 97 in B94

Product Description

The CONTINENTAL CONTITECH 20042112 is a Section B classical V-belt designed for power transmission in HVAC, industrial, and mechanical drive applications. Built from Wingprene rubber-impregnated fabric, this belt delivers reliable flex and heat resistance across a wide operating temperature range of -40 degrees F to 284 degrees F (equivalent to -40 degrees C to 140 degrees C). It carries the industry designation B94, with a 97.0-inch outside length and an 95.80-inch internal length. The HY-T Matchmaker style ensures consistent cross-sectional geometry for matched-set applications. Licensed HVAC technicians, millwrights, and equipment service technicians are the primary installers.

This belt is suited for residential and light commercial HVAC blower drives, condenser fan drives, and general-purpose mechanical equipment using standard Section B sheaves and pulleys. The B94 designation makes it a direct specification match for OEM and replacement drive systems that call out a B-section belt at this length. It is sold individually and is appropriate wherever a single B94 belt is required, including retrofit and maintenance replacement scenarios on air handlers, rooftop units, and belt-driven fans.

Key Features

• Section B profile with 97.0-inch outside length and 95.80-inch internal length for precise drive fitment
• Wingprene rubber-impregnated fabric construction resists heat, oil mist, and flex fatigue
• Wide operating range from -40 degrees C to 140 degrees C suits demanding HVAC and industrial environments
• HY-T Matchmaker style maintains uniform cross-section geometry, supporting matched-set use on multi-belt drives
• B94 belt number provides a direct specification reference for OEM replacement and aftermarket sourcing

Compatibility

Designed as an OEM-style replacement for any drive system specifying a Section B V-belt with a B94 designation and 97.0-inch outside length using standard Section B sheaves.

Installation Notes

Belt replacement should be performed by a qualified HVAC technician or maintenance mechanic. Disconnect and lock out all power to the equipment before removing belt guards or accessing drive components. Adjust sheave center distance to relieve tension before removing the old belt, then seat the new belt without forcing it over sheave flanges. After installation, set tension per the equipment manufacturer specification and verify alignment before restoring power.
