Continental Contitech 20042076 V-belt Section B B58 61 in

Product Description

The CONTINENTAL CONTITECH 20042076 is a Section B classical V-belt designed for power transmission in HVAC, industrial, and mechanical drive applications. Built from Wingprene rubber-impregnated fabric, this belt delivers reliable flex and heat resistance across a wide temperature range, from -40 degrees F to 284 degrees F (approximately -40 degrees C to 140 degrees C). With an outside length of 61 inches and an internal length of 59.80 inches, it matches the standard B58 belt designation. It weighs 0.7 pounds and is sold individually. HVAC technicians, mechanical contractors, and maintenance professionals install this belt on fan and blower drive systems.

This belt is suited for residential and light commercial HVAC systems as well as general mechanical drive applications where a Section B V-belt is specified. The HY-T Matchmaker style designation indicates it is engineered for use in matched-set drive systems where belt uniformity and dimensional consistency are critical. It is commonly installed on air handler blowers, condenser fan drives, and belt-driven exhaust systems requiring a B58-sized belt.

Key Features

• Section B profile with 61-inch outside length matches standard B58 belt designation
• Wingprene rubber-impregnated fabric construction resists heat, oil, and flex fatigue
• Operating temperature range from -40 degrees C to 140 degrees C for demanding environments
• HY-T Matchmaker style supports matched-set drive system applications
• 59.80-inch internal length for precise sheave fitment
• Lightweight at 0.7 pounds for easy single-technician installation

Compatibility

Designed as a direct replacement for applications requiring a standard B58 Section B V-belt. Confirm sheave groove profile and center-to-center distance against drive specifications before installation.

Installation Notes

A licensed HVAC technician or qualified mechanical contractor should install this belt. De-energize the equipment and lock out or tag out the disconnect before servicing the drive system. Use a belt tension gauge to set proper tension after installation — do not pry the belt over sheave flanges, as this can damage the cord structure. Inspect sheave grooves for wear before installing a new belt.
