Continental Contitech 20042017 a Section V-belt 94.2 in

Product Description

The CONTINENTAL CONTITECH 20042017 is a Section A V-belt designed for power transmission in mechanical drive systems. Built from Wingprene rubber-impregnated fabric, this belt carries the HY-T Matchmaker designation and meets DIN 2215 and DIN 7753 standards. It has an outside length of 94.2 inches and an internal length of 93.30 inches. The construction provides resistance to both heat and oil, with a working temperature range of -40 degrees C to 140 degrees C. HVAC technicians, industrial maintenance mechanics, and equipment service professionals install this belt in blower, fan, and motor drive applications.

This V-belt is suited for residential and commercial HVAC blower assemblies, refrigeration unit drives, and general industrial power transmission setups where a standard Section A belt is specified. The oil-resistant and heat-resistant Wingprene construction makes it appropriate for installations near motors, compressors, or other heat-generating equipment. Its compliance with DIN 2215 and DIN 7753 ensures dimensional consistency for replacement and matched-set applications.

Key Features

• Section A V-belt profile with 94.2 inches outside length and 93.30 inches internal length
• Wingprene rubber-impregnated fabric construction for durability under mechanical stress
• Heat resistant up to 140 degrees C and oil resistant for demanding drive environments
• Wide working temperature range from -40 degrees C to 140 degrees C
• Meets DIN 2215 and DIN 7753 dimensional and performance standards
• HY-T Matchmaker style for use in matched-set multi-belt drive configurations

Compatibility

Designed as an OEM-style replacement Section A V-belt for HVAC blower drives, fan drives, and general industrial power transmission systems specifying a standard A92 belt.

Installation Notes

Belt replacement is performed by qualified HVAC technicians or mechanical maintenance personnel. Disconnect and lock out all power to the drive system before removing the old belt or installing the new one. Adjust sheave or pulley spacing to allow belt installation without forcing the belt over the groove, then tension according to the equipment manufacturer specification. Inspect sheave grooves for wear or damage before installing a new belt, as worn grooves accelerate belt wear.
