Continental Contitech 20041996 Section a V-belt A71 73.2 in

Product Description

The CONTINENTAL CONTITECH 20041996 is a Section A V-belt designed for power transmission applications in industrial and commercial equipment. Constructed from Wingprene rubber-impregnated fabric, this belt delivers reliable performance across a wide temperature range, rated from -40 degrees C to 140 degrees C. With an outside length of 73.2 inches and an internal length of 72.30 inches, it carries the industry designation A71. The HY-T Matchmaker style profile ensures consistent engagement with standard A-section sheaves, making it a dependable replacement for worn or failed drive belts in a range of mechanical systems.

This V-belt is suited for HVAC blower drives, refrigeration condensing unit fan drives, industrial machinery, and general power transmission applications where Section A belt sizing is required. It is appropriate for both residential and light commercial equipment installations. Technicians working on air handling units, belt-drive fans, compressors, and similar rotating equipment will find this belt a direct-fit option wherever an A71 designation is called out.

Key Features

• Section A profile with 73.2-inch outside length and 72.30-inch internal length, matching the A71 belt designation
• Wingprene rubber-impregnated fabric construction provides heat resistance and oil resistance
• Rated for operation from -40 degrees C to 140 degrees C for reliable performance in demanding environments
• HY-T Matchmaker style profile for consistent sheave engagement and reduced vibration
• Meets DIN 2215 and DIN 7753 standards for dimensional and performance compliance

Compatibility

Designed as an OEM-style replacement V-belt for equipment requiring a Section A, A71-designation drive belt in standard A-section sheave configurations.

Installation Notes

V-belt replacement should be performed by a qualified technician. Always disconnect and lock out power to the equipment before removing any belt guards or accessing drive components. When installing, do not pry or force the belt over sheave flanges; adjust the drive to allow slack for proper seating, then tension according to the equipment manufacturer's specifications. Inspect sheaves for wear or misalignment before installing a new belt to avoid premature failure.
