Continental Contitech 20041980 V-belt Section a A55 57.2 in

Product Description

The CONTINENTAL CONTITECH 20041980 is a Section A V-belt designed for power transmission in HVAC, refrigeration, and general mechanical equipment. Built from Wingprene rubber-impregnated fabric, this belt is engineered to handle demanding environments with a working temperature range of -40 degrees C to 140 degrees C. With an outside length of 57.2 inches and a belt number designation of A55, it provides reliable grip and load transfer in belt-driven systems. Licensed HVAC technicians and mechanical contractors install this type of belt during routine preventive maintenance and equipment repair cycles.

This belt is suited for residential and light commercial HVAC units, refrigeration condensing units, and other belt-driven mechanical systems that require a standard Section A profile. The A55 designation follows DIN 2215 and DIN 7753 standards, making it appropriate for use in equipment where dimensional compliance to those specifications is required. Its Wingprene construction resists oil contamination and heat buildup, which are common stress factors in compressor and blower drive applications.

Key Features

• Wingprene rubber-impregnated fabric construction for heat and oil resistance
• Section A profile with 57.2 inches outside length and 56.30 inches internal length
• Working temperature range from -40 degrees C to 140 degrees C
• Compliant with DIN 2215 and DIN 7753 standards
• HY-T Matchmaker style for matched-set compatibility
• Single-belt packaging with a minimum order quantity of one

Compatibility

Designed as an OEM-style replacement V-belt for belt-driven HVAC, refrigeration, and mechanical equipment requiring a Section A profile belt with an A55 designation per DIN 2215 and DIN 7753 standards.

Installation Notes

V-belt replacement should be performed by a qualified technician. Disconnect and lock out all power to the unit before removing the belt guard or accessing the drive system. Check sheave alignment and inspect pulleys for wear before installing the new belt. Avoid prying the belt onto the sheave with sharp tools, as this can damage the belt fabric and reduce service life.
