Conbraco 94-MBV-05 1/8 x 1/8, FPT x FPT, 600 PSI, Chrome Plated Brass Ball Valve

Product Description

The Conbraco 94-MBV-05 is a heavy-duty ball valve made from forged brass. It features a reversible lever handle and is designed for a variety of applications including water, oil, and gas. This valve has a full port and offers a pressure rating of 600 PSI at one hundred degrees Fahrenheit. It is ideal for commercial and light industrial use.

• Part Number: 94-MBV-05
• Nominal Size: 1/8 inch x 1/8 inch
• Temperature Rating: -40 to 300 degrees Fahrenheit

Product Highlights

This ball valve provides reliable operation with a blowout-proof stem design and large raised wrench flats for easy installation. The chrome plated brass ball ensures optimal flow and durability.

Product Information

Standard Information

• Brand: Conbraco
• MPN: 94-MBV-05

Technical Specifications

• Actuation Type: Reversible Lever Handle
• End Connection: Female Threaded x Female Threaded
• End to End Distance: 1.68 inches
• Ball Material: Chrome Plated Brass
• Body Material: Forged Brass
• Pressure Rating: 600 PSI at 100 degrees Fahrenheit
• Seal Material: Viton O-Ring
• Seat Material: TFE
• Stem Material: Brass
• Port Type: Full
• Inclusions/Features: Blowoutproof Stem Design, Double Viton O-Ring Stem Seal
• Applicable Standard: ASME B16.44, ANSI Z21.15, CSA 9.1
