Product Description
The CONBRACO 93-108-01 is a 2 IN uni-body reduced port standard ball valve. Constructed with a carbon steel body, this valve features a lever handle operator and RPTFE seats. It is designed to handle pressure up to 1500 PSI (CWP) and 150 PSI (SWP), with a temperature rating up to 500 DEG F.
- Uni-Body design
- Features a reduced port
- Equipped with a lever handle
Product Highlights
This ball valve is suitable for various applications, offering reliable performance and durability with its robust construction and design.
Product Information
Standard Information
-
Brand: CONBRACO
-
Manufacturer Part Number: 93-108-01
Technical Specifications
-
Series/Model: Series 93-100
-
Nominal Size: 2 IN
-
Connection Type: FNPT
-
Pressure Rating: 1500 PSI (CWP), 150 PSI (SWP)
-
Temperature Rating: Up To 500 DEG F
-
Opening: 1-1/4 IN
-
Body Material: Carbon Steel
-
Operator Type: Lever Handle
-
Handle Material: Steel With Vinyl Grip
-
Stem Material: Carbon Steel
-
Trim Material: Carbon Steel Ball
-
Packing Material: MPTFE Stem
-
Seat Material: RPTFE
-
Ball Material Standard: ASTM A108
-
Handle And Stem Finish/Color: Zinc Plated
-
Ball Finish: Chrome Plated
-
Industry Standards: MSS-SP-110 Compliant, API 607
-
Width: 4.71 IN
-
Lead Free: No
-
Flow Co-Efficient (Cv): 62
-
Media: Gas, Water
-
Port Type: Reduced
-
End Style: Threaded
-
Type: Ball Valve
-
Manufacturer: Aalberts Integrated Piping Systems
-
Category: Ball Valves
-
Configuration: Standard
-
Domestic/Import: Domestic
-
Ball Material: Carbon Steel
