Conbraco 76F-103-01A 1/2 Ss Fp Ball Valve

Brand: CONBRACO
SKU: 76F-103-01A
Availability: Out Of Stock
$63.43
$63.43
HAVE A QUESTION?

Our team is ready to help!

215-326-9845
  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Description

Product Description

The CONBRACO 76F-103-01A is a full-port standard ball valve with a stainless steel body. It features a 1/2 IN nominal size and FNPT connection type. Designed for durability, it has a pressure rating of 1000 PSI (CWP) and a temperature rating of 0 - 500 DEG F. The valve includes a lever handle operator and RPTFE seats and seals.

  • Full-Port
  • Standard Ball Valve
  • Stainless Steel Body
  • Lever Handle Operator

Product Highlights

This ball valve is ideal for applications requiring robust performance and corrosion resistance.

Product Information

Standard Information

  • Brand: CONBRACO
  • Manufacturer Part Number: 76F-103-01A
  • Country of Origin: United States
Technical Specifications
Series/Model
Series 76F-100-A
Nominal Size
1/2 in
Connection Type
FNPT
Pressure Rating
1000 PSI (CWP), 150 PSI (SWP)
Temperature Rating
0 - 500 DEG F
Opening
1/2 IN
Body Material
A351-CF8M Stainless Steel
Operator Type
Lever Handle
Handle Material
Stainless Steel w/ Vinyl Grip
Stem Material
A276-316 Stainless Steel
Trim Material
316 Stainless Steel/PTFE
Packing Material
RPTFE Stem, 316 Stainless Steel Gland
Seat Material
RPTFE
Seal Material
RPTFE
Material Standard (Body)
ASTM A351 Grade CF8M
Material Standard (Stem And Gland)
ASTM A276
Material Standard (Ball)
ASTM A276
Industry Standards
MSS-SP-110 Compliant, Fire tested API 607, 6th Edition, Meets NACE MR0175 (2000) And MR0103 (2012), CSA/CAN 3.16-M88 (2009), NSF/ANSI 61 (2010) Section 8, Annex F And G, NSF-372, Drinking Water System Components - Lead Content
Width
2.35 IN
Lead Free
Yes
Other Physical Dimension
1.73 IN Inlet Center To Top Of Handle, 3.85 IN Handle Length
Flow Co-Efficient (Cv)
15
Series
76F-100
Body Style
2 piece
Control Type
Manually Operated
Handle Style
Lever Handle
Ball Material
A276-316SS Stainless Stainless
Mounting Type
Inline Threaded
Porting Style
Full Port
Stem Seal Material
MPTFE
Valve Body Material
CF8M Stainless Steel
Maximum Operating Pressure
1000 psi
O-Ring Material
RPTFE
Flow Direction
2-Way
Overall Length
2.35 in
Port Size
1/2 NPT
Standards
MSS SP-110 Compliant
Media Pressure Rating
Steam - 150 psi, Cold Water - 1000 psi
Inlet to Outlet Length
2.35 in
Actuator Type
Lever Operated
Softgoods Material
MPTFE
Top to Inlet Center
1.73 in
Type
2-Piece
Includes
Adjustable Packing Gland
Warranty
5 Years
Domestic/Import
Domestic
