Conbraco 70LF-202-01 3/8 Lead Free Brz Sweat Ball Valve

Product Description

The CONBRACO 70LF-202-01 is a 2-Piece In-Line Standard Ball Valve, part of the Series 70LF-200. This lead-free bronze ball valve features a 3/8 IN nominal size and compression (solder) connection type. It is designed with a pressure rating of 600 PSI (CWP) and 150 PSI (SWP), and a temperature rating of -50 to 450 DEG F.

• 2-Piece In-Line Standard Ball Valve
• Lead Free
• Lever Handle Operator Type

Product Highlights

This valve is MSS-SP-110 compliant and certified to NSF/ANSI 61-8, Annex G, and NSF/ANSI 372 standards.

Product Information

Standard Information

• Brand: CONBRACO
• Manufacturer Part Number: 70LF-202-01
• Country of Origin: USA

Technical Specifications

• Series/Model: Series 70LF-200
• Nominal Size: 3/8 IN
• Connection Type: Compression (Solder)
• Pressure Rating: 600 PSI (CWP), 150 PSI (SWP)
• Temperature Rating: -50 To 450 DEG F
• Opening: 0.37 IN
• Body Material: Lead Free Bronze
• Handle Operator Type: Lever Handle
• Handle Material: Steel With Vinyl Grip
• Stem Material: Brass
• Trim Material: Brass Stem and RPTFE Seat
• Packing Material: RPTFE Stem
• Seat Material: Reinforced Polytetrafluroethylene
• Seal Material: Reinforced Polytetrafluroethylene
• Body Material Specification: UNS C89836
• Ball And Stem Material Specification: UNS C27451
• Handle Finish/Color: Zinc Plated
• Ball Finish: Chrome Plated
• Industry Standards: MSS-SP-110 Compliant, NSF /ANSI 61-8, Annex G, NSF/ANSI 372, NSF /ANSI 372 Lead Free ANSI 3rd Party Certified
• Width: 2.56 IN
• Lead Free: Yes
• Other Physical Dimension: 1-3/4 IN Inlet Center To Top Of Handle, 3.87 IN Handle Length
• Item Name: In-Line Standard Ball Valve
• Type: 2-Piece
• Opening Size: 0.37 IN
• Operator Type: Lever Operated
• Material Specification: Body: UNS C89836, Ball And Stem: UNS C27451
• Finish/Color: Zinc Plated Handle, Chrome Plated Ball
• Actuator Type: Lever Operated
• Ball Material: Chrome Plated Brass
• Domestic/Import: Domestic
• End Style: Solder
• Inlet to Outlet Length: 2.56 in
• Port Type: Standard
• Series: 70LF-200
• Softgoods Material: RPTFE
• Top to Inlet Center: 1-3/4 in
• Valve Type: Standard Ball Valve
• Pipe Size: 3/8
• Valve Structure: 2-Piece
• End Connection: Soldered x Soldered
• Handle Type: Lever
• Standards: MSS SP-110 Compliant
• Maximum Working Temperature (F): 350
• Wsp Rating: 150psi
