Conbraco 70LF-104-HC Ball Valve 3/4 NPT X 3/4 Hose

Product Description

The CONBRACO 70LF-104-HC is a 2-Piece Full-Port In-Line Ball Valve With Cap. It has a nominal size of 3/4 IN and a connection type of NPT X Hose Thread. The valve has a pressure rating of 600 PSI (CWP) and a temperature rating of Up To 210 DEG F.

• 2-Piece Full-Port In-Line Ball Valve With Cap
• Lead Free
• The Apollo® 70LF-HC models are ideally suited for direct connection to hoses.

Product Highlights

This ball valve is designed for plumbing and heating systems, including potable water. It features lead free brass and bronze materials and is 100% factory tested in the USA.

Product Information

Standard Information

• Brand: CONBRACO
• Manufacturer Part Number: 70LF-104-HC
• Country of Origin: USA

Technical Specifications

• Series/Model: Series 70LF-100-HC
• Nominal Size: 3/4 IN
• Connection Type: NPT X Hose Thread
• Pressure Rating: 600 PSI (CWP)
• Temperature Rating: Up To 210 DEG F
• Opening: 0.68 IN
• Body Material: Bronze
• Operator Type: Lever Handle
• Handle Material: Stainless Steel With Vinyl Grip
• Stem Material: Brass
• Trim Material: Brass Stem and RPTFE Seat
• Packing Material: MPTFE Stem
• Seat Material: RPTFE
• Seal Material: PTFE
• Body Material Specification: UNS C89836
• Ball And Stem Material Specification: UNS C27451
• Industry Standards: MSS-SP-110 Compliant, ANSI/NSF 61, ANSI/NSF 372
• Width: 3.67 IN
• Lead Free: Yes
• Inlet Center To Top Of Handle: 2.12 IN
• Handle Length: 4.87 IN
• End Style: FNPT
• Port Type: Standard
• Softgoods Material: RRPTFE
• Actuator Type: Lever
• Ball Material: Chrome Plated Brass
• Inlet to Outlet Length: 3
• Manufacturer: Apollo Conbraco
• Manufacturer #: 70LF-104-HC
• Series: 70LF-100-HC
• Top to Inlet Center: 2.12
• Type: 2-Piece
• Opening Size: 0.68 IN
• Material Specification: Body: UNS C89836, Ball And Stem: UNS C27451
• Weight: 1.390 LB
• Domestic / Import: Domestic
