CONBRACO Conbraco 70-608-01 2 in Brz 3-Way Std Ball Valve
CONBRACO Conbraco 70-608-01 2 in Brz 3-Way Std Ball Valve

Conbraco 70-608-01 2 in Brz 3-Way Std Ball Valve

Brand: CONBRACO
SKU: 70-608-01
Availability: In Stock

Ships same day if ordered by 12 pm
$253.58
$253.58
HAVE A QUESTION?

Our team is ready to help!

215-326-9845
  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Description

Product Description

The CONBRACO 70-608-01 is a 2 IN 2-piece standard ball valve from the 70-600 series, designed with a 3-way configuration. It features a bronze body, lever handle, and FNPT connection. This valve is suitable for tank selection and fluid transfer applications. It has a pressure rating of 400 PSI (CWP) and a temperature rating of 0 - 500 DEG F.

  • 2-Piece Standard Ball Valve
  • 3-Way
  • Bronze Body
  • Lever Handle

Product Highlights

Standard port 3-way diversion valve ideal for making tank selection and fluid transfers simpler.

Product Information

Standard Information

  • Brand: CONBRACO
  • Manufacturer Part Number: 70-608-01
  • Country of Origin: United States
Technical Specifications
Series/Model
Series 70-600
Nominal Size
2 IN
Connection Type
FNPT
Ports/Ways
3-Way
Pressure Rating
400 psig
Temperature Rating
0 - 500 DEG F
Opening
1-1/2 IN
Body Material
Bronze
Operator Type
Lever Handle
Handle Material
Zinc Plated Steel with Vinyl Grip
Stem Material
Brass
Trim Material
Brass Ball
Seat Material
RPTFE
Seal Material
PTFE
Material Standard (Body)
ASTM B584
Material Standard (Ball And Stem)
ASTM B16
Material Specification (Body)
UNS C84400
Finish/Color
Zinc Plated Handle, Chrome Plated Ball
Industry Standards
MSS-SP-110 Compliant, WW-V-35C Federal Specification, CRN: OC10908.5C
Width
4.69 IN
Lead Free
No
Other Physical Dimension
3 IN Inlet Center To Top Of Handle, 5-1/2 IN Handle Length
Flow Co-Efficient (Cv)
47 Cv
Pipe Size
2 in
Stem Type
Blowout Proof
Body Style
3-Way
Connection
Threaded
Valve Size
2 NPT
Handle Type
Lever
Ball Material
Chrome Plated Brass
Porting Style
Standard Port
Standards Met
MSS-SP-110
Overall Length
9.05 in
Valve Structure
2-Piece
Maximum Pressure
400 psi CWP
Temperature Range
-20 to 450 °F
Body Seal Material
PTFE
Stem Seal Material
MPTFE
Valve Body Material
Bronze
Media Pressure Rating
Cold Water - 400 psi
Compliance Specifications
ISO 9001
Actuator Type
Lever
Configuration
Standard
Domestic/Import
Domestic
Number of Ports/Ways
3-Ways
Orifice Size
1-1/2 in
Packing Material
RPTFE
Port Type
Standard
Series
70-600 Series
Top to Inlet Center
3.07 in
Material
Bronze
End Style
Threaded
Type
Ball Valve 3-Way L-Port
