Conbraco 70-203-HC 1/2 solder x 3/4 hose brz ball valve w/cap and chain

Product Description

The CONBRACO 70-203-HC is a 2-piece standard port ball valve with cap and chain. Featuring solder x hose connection, this valve is designed to be soft soldered into lines without disassembly. It has a pressure rating of 600 PSI (CWP) and a temperature rating of -20 to 500 DEG F. The valve has a bronze body and a brass stem.

• 2-Piece Standard Port Ball Valve
• With Cap And Chain
• Bronze Body Material

Product Highlights

This ball valve offers trusted performance with premium materials and heavy-duty construction. It is suitable for general purpose use.

Product Information

Standard Information

• Brand: CONBRACO
• Manufacturer Part Number: 70-203-HC

Technical Specifications

• Series/Model: Series 70-200-HC
• Nominal Size: 1/2 X 3/4 IN
• Connection Type: Solder X Hose
• Pressure Rating: 600 PSI (CWP)
• Temperature Rating: -20 To 500 DEG F
• Opening: 1/2 IN
• Body Material: Bronze
• Handle Operator Type: Reverse Lever
• Handle Material: Stainless Steel With Vinyl Grip
• Stem Material: Brass
• Trim Material: Brass Stem and RPTFE Seat
• Packing Material: MPTFE Stem
• Seat Material: RPTFE
• Body Material Standard: ASTM B584
• Ball Material Standard: ASTM B16 Or ASTM B283
• Stem Material Standard: ASTM B16
• Body Material Specification: UNS C84400
• Ball Material Specification: UNS C37700
• Finish/Color: Chrome Plated Ball
• Industry Standards: MSS-SP-110 Compliant
• Width: 3.28 IN
• Lead Free: No
• Other Physical Dimension: 1-3/4 IN Inlet Center To Top Of Handle, 3.89 IN Handle Length
• Domestic / Import: Domestic
• End Style: solder
• Port Type: Standard
• Softgoods Material: MPTFE
• Actuator Type: Lever
• Ball Material: Chrome Plated Brass
• Inlet to Outlet Length: 2.87 IN
• Manufacturer: Apollo Conbraco
• Manufacturer #: 70-203-HC
• Media: Water
• Type: 2-Piece
• Model Number: 70203HC
• Size: 1/2 IN
• Options: Cap and Chain
• End to end distance: 3.32 IN
• With: Cap and Chain
• MPN: 70203HC
• Manufacturer Part Number: 70203HC
• UPC / GTIN: 670750521829
• Valve Type: Ball Valve
