Conbraco 70-203-01 1/2 Brz Sweat Std Ball Valve

Product Description

The CONBRACO 70-203-01 is a 2-Piece In-Line Standard Ball Valve, part of the Series 70-200. It features a solder connection type and is made with a bronze body. Designed for durability, it withstands a pressure rating of 600 PSI (CWP) and 150 PSI (SWP). The valve is suitable for temperatures ranging from -20 to 500 DEG F.

• Bronze body material conforming to ASTM B584 standard.
• Steel lever handle with vinyl grip for manual operation.
• Suitable for a wide range of applications with a flow coefficient (Cv) of 15.

Product Highlights

This bronze ball valve offers reliable performance with its robust construction and compliance with industry standards like MSS-SP-110 and CSA B51.

Product Information

Standard Information

• Brand: CONBRACO
• Manufacturer Part Number: 70-203-01

Technical Specifications

• Series/Model: Series 70-200
• Nominal Size: 1/2 IN
• Connection Type: Sweat x Sweat
• Pressure Rating: 600 PSI (CWP), 150 PSI (SWP)
• Temperature Rating: -20 To 500 DEG F
• Opening: 1/2 IN
• Body Material: C84400 Cast Bronze
• Handle Operator Type: Lever Handle
• Handle Material: Vinyl/Zinc-Plated Steel
• Stem Material: Brass
• Trim Material: C37700 Forged Brass/Zinc-Plated Steel
• Packing Material: MPTFE
• Seat Material: RPTFE
• Seal Material: PTFE
• Body Material Standard: ASTM B584
• Ball And Stem Material Standard: ASTM B16
• Body Material Specification: UNS C84400
• Handle Finish/Color: Zinc Plated
• Ball Finish: Chrome Plated
• Industry Standards: MSS-SP-110 Compliant, CSA B51, CRN: OC10908.5C
• Width: 2.87 IN
• Lead Free: No
• Inlet Center To Top Of Handle: 1-3/4 IN
• Handle Length: 3.87 IN
• Flow Co-Efficient (Cv): 15
• Pipe Size: 1/2 in
• Stem Type: Blowout Proof
• Body Style: Inline
• Connection: Sweat
• Valve Size: 1/2 in
• Handle Style: Lever
• Ball Material: C37700 Chrome-Plated Brass
• Porting Style: Standard Port
• Standards Met: MSS SP-110, ASTM B16
• Overall Length: 2.87 in
• Valve Structure: 2-Piece
• Maximum Pressure: 600 psi CWP
• Body Seal Material: PTFE
• Stem Seal Material: MPTFE
• Valve Body Material: Bronze
• Media Pressure Rating: Cold Water - 600 psi, Steam - 150 psi
• Maximum Steam Pressure: 150 PSI WSP
• Compliance Specifications: MSS SP-110
• Flow Coefficient (Cv) / Flow Factor (Kv): 15 Cv
• Actuator Type: Lever
• Domestic/Import: Domestic
• Inlet to Outlet Length: 2.87 in
• Material Standard: ASTM B16, ASTM B283, ASTM B584
• Opening Size: 0.63 in
• Orifice Size: 1/2 in
• Port Type: Standard
• Softgoods Material: MPTFE/RPTFE
• Top to Inlet Center: 1-3/4 in
• CWP: 600
• Material: Bronze
• Pieces: 2
• Size: 1/2 in
• Type: Sweat
