Product Description
The Conbraco 30LF-038-01 is a gate valve designed for plumbing applications. It features a nominal size of two inches and is suitable for use with potable water systems. This valve operates with a handwheel for easy control and includes a solid wedge disc for efficient flow management.
- Lead-Free bronze construction
- Pressure rated to 125 PSI SWP and 200 PSI CWP
- Adjustable graphite stem packing
Product Highlights
The 30LF-038-01 valve is built for durability and reliability in commercial applications.
Product Information
Standard Information
-
Manufacturer: Conbraco
-
UPC: 67075068700
Technical Specifications
-
Nominal Size: 2 inches
-
Body Material: ASTM B584 C89836 Bronze
-
Bonnet Material: ASTM B584 C89836 Bronze
-
Stem Material: ASTM B21 UNS C46400 Brass
-
Seal Material: Grafoil
-
Wedge Material: ASTM B584 C89836 Bronze
-
Temperature Rating: -20 to 406 degrees F
-
Pressure Rating: 125 PSI SWP, 200 PSI CWP
-
End Connection: Threaded x Threaded
-
End to End Distance: 3.06 inches
-
Flow Rate: 338 Cv
-
Application: Commercial, Potable Water
-
Applicable Standard: CSA B51, NSF/ANSI 61/372, MSS SP-80/139
