Conbraco 19KHGK11 1-1/2 x 2, MPT x FPT, 11 PSI, Bronze, Safety Relief Valve

Product Description

The Conbraco 19KHGK11 is a safety relief valve designed for high-pressure applications. This valve features a one and one-half inch inlet and a two-inch outlet. It connects via male threaded and female threaded ends. Made from ASTM B584 bronze, it provides reliability and durability in various settings.

• Wide wrenching hex for easier installations
• Spring and stem made from stainless steel
• Non-stick PFA seat designed to resist corrosion

Product Highlights

This valve is ideal for use in boilers, sterilizers, and pneumatic conveying systems. It meets CE and ASME standards, ensuring safety and quality.

Product Information

Standard Information

• Manufacturer: Conbraco
• Product ID: 40202

Technical Specifications

• Inlet Size: 1-1/2 inches
• Outlet Size: 2 inches
• Set Pressure Range: 11 PSI
• Body Material: ASTM B584 Bronze
• Spring Material: Stainless Steel
• Temperature Rating: 406 Deg F
• Disc Material: Brass
• Seal Material: Stainless Steel
• Seat Material: PFA Non-Stick
• End Connection: Male Threaded x Female Threaded
• Applications: Suitable for boiler, sterilizer, cooker, compressor, and pressure piping systems.
• Applicable Standards: CE, CSA B51, ASME Section VIII, ISO 9001
