Comtran 2836 16 AWG 2-Conductor Stranded Copper Chrome Gray PVC Jacket Unshielded Riser Sound and Security Cable

Product Description

The Comtran Cable 2836 is suitable for various low-voltage applications. This cable has two 16 AWG conductors made from nineteen strands of bare copper. This design offers flexibility and improved conductivity. The cable insulation is made of a zero point zero zero nine inch nominal wall SR PVC, while the outer jacket is a durable zero point zero one four inch nominal wall Chrome Gray PVC. It also features a parallel ripcord which aids in easier stripping. This cable is intended for use in power-limited circuits and fire alarm systems in vertical riser installations.

• Constructed with two 16 AWG 19 strand bare copper conductors.
• Durable zero point zero one four inch nominal wall Chrome Gray PVC jacket.
• UL Listed as Type CL3R/FPLR and C(UL)US Type CMR with California State Fire Marshal Approval.

Product Highlights

This cable meets specific safety and performance standards, making it ideal for sound and security applications.

Product Information

Standard Information

• Conductor Gauge: 16 AWG
• Number of Conductors: 2

Technical Specifications

• Conductor Type: 19 strand bare copper
• Insulation Material: SR PVC
• Insulation Nominal Wall: zero point zero zero nine inches
• Jacket Material: Chrome Gray PVC
• Jacket Nominal Wall: zero point zero one four inches
• Nominal Outer Diameter (O.D.): zero point one seven six inches
• Conductor Color Code: Black, Red
• DC Resistance: four point two seven ohms/Kft max @ 20C
• Capacitance: twenty one pF/ft nominal conductor - conductor
• UL Standards Met: UL 13, UL 1424, UL 444, UL 1666
• NEC Article Compliance: NEC Article 725, 760 and 800
• Certifications: UL Listed Type CL3R/FPLR, C(UL)US Type CMR, California State Fire Marshal Approved
