Component Manufacturing Corporation 1649 Connector Housing

Product Description

The Component Manufacturing Corporation 1649 is a connector housing designed for wire harness connections. This housing is compatible with the 58 Connector S Type, featuring a four-pole male connector. Made from NYLON 6, the housing is suitable for a wide range of applications. It remains effective across a temperature range from minus forty to one hundred degrees Celsius.

• Connector type: Wire harness connector
• Number of poles: 4
• Material: NYLON 6

Product Highlights

Durable and effective for wire harness connections, the 1649 connector housing is designed to maintain performance under various temperature conditions.

Product Information

Standard Information

• Part: Housing
• Family: 58 Connector S Type

Technical Specifications

• Connection Type: Wire Harness Connector
• Sealed: Unsealed
• Gender: Male
• Number of Poles: 4
• Tab Size: 2.80 mm
• Material: NYLON 6
• Length: 36.00 mm
• Width: 18.60 mm
• Height: 22.60 mm
• Color: Blue
• Clip Installation Structure: Yes
• Allowable Current: 10A
• Insulation Resistance: 100Megohm Min. at 500VDC
• Withstand Voltage: 1000V AC (1min.)
• Temperature Range: -40 to 100 degrees Celsius
