Color-Keyed 54811 CONNECTOR SPLC 3/0AWG COPPER 50 2-1/4IN

Product Description

Color-Keyed® Connector, MPN 54811, is a two-way long barrel splice connector for copper conductors. This connector is designed to accommodate 3/0 AWG copper wiring and operates with a maximum voltage rating of 600 VAC.

• Compatible with a color-coded compression system for easy installation.
• Die code 50 ensures proper matching with installation tools.
• Constructed from tin-plated copper with an outside diameter of 0.65 inches.

Product Highlights

This connector provides high-quality, low-resistance connections and is suitable for applications certified up to 35 kV.

Product Information

Standard Information

• Catalog Number: 54811
• Manufacturer: ABB - Installation Products

Technical Specifications

• Conductor Size: 3/0 AWG
• Length: 2-1/4 inches
• Voltage Rating: 600 VAC
• Color Code: Orange
• Die Code: 50
• Material: Copper
• Finish: Tin-Plated
• Application: Suitable for high pullout values and easy insulation
