Color-Keyed 54505 Connector Splice 6AWG Copper 1 in

Product Description

The Color-Keyed 54505 Connector is designed for splicing 6 AWG copper conductors with ease. This connector is a two-way standard barrel splice connector equipped with a die code of 24. It is suitable for high-quality and low resistance connections.

• Easy installation with color-coded matching for the correct tools.
• Provides high pullout values and reliable load handling.
• Rated for up to 600 VAC and maximum voltage of 35 kV.

Product Highlights

The Color-Keyed compression system ensures a proper crimp onto the conductor, using a matching connector to the right tool and die.

Product Information

Standard Information

• Brand: Color-Keyed
• Manufacturer: ABB - Installation Products

Technical Specifications

• Length: 1 in
• Voltage Rating: 600 VAC
• Conductor Size: 6 AWG
• Conductor Type: Copper
• Outside Diameter: 0.3 in
• Die Code: 24
• Color Code: Blue
• Material: Copper
