Coilhose Pneumatics RP0606S Lead-in Whip Hose 3/8 in

Product Description

The COILHOSE PNEUMATICS RP0606S is a lead-in whip hose designed to serve as the flexible connection point between a stationary air supply line and a pneumatic tool or hose assembly. Built from neoprene, it handles working pressures up to 200 psi and operates across a temperature range of -40 to 212 degrees F. At 1/2 foot in length, it provides the short, controlled flex needed at the tool end without adding excess slack. End connections are FNPT x MNPT swivel, allowing the fitting to rotate for easier tool attachment and reduced hose twist during use. Licensed contractors and industrial pneumatic technicians working with compressed air systems are the primary installers of this component.

This whip hose is suited for use in compressed air distribution systems found in automotive shops, manufacturing floors, mechanical rooms, and field service environments. The 3/8 inch inside diameter and 3/8 inch fitting size support standard air tool connections commonly used in those settings. The MNPT swivel fitting at the tool end reduces torsional stress on the hose during operation, extending service life in high-cycle applications.

Key Features

• Neoprene construction rated for -40 to 212 degrees F operating range
• 200 psi maximum working pressure
• 3/8 inch inside diameter with 3/8 inch fitting size
• FNPT x MNPT swivel end connections reduce hose twist at the tool
• Compact 1/2 foot length for use as a lead-in or whip section

Compatibility

Designed as an OEM-style replacement or drop-in addition for compressed air distribution systems using 3/8 inch NPT connections and standard pneumatic tool fittings.

Installation Notes

Installation is typically performed by a qualified pneumatic technician or industrial mechanic. Depressurize and lock out the air supply line before connecting or disconnecting any hose assembly. Apply thread sealant to NPT fittings per standard practice and verify all connections are leak-free before returning the system to service. Do not exceed the rated 200 psi working pressure.
