Coilhose Pneumatics PE064-100KD Polyethylene Tube 100 Ft

Product Description

The COILHOSE PNEUMATICS PE064-100KD is a flexible black polyethylene pneumatic tube rated for demanding shop and industrial air-line applications. Measuring 0.375 inches outside diameter and 0.250 inches inside diameter, it ships as a 100-foot coil weighing 2.3 pounds. The tube handles a maximum working pressure of 192 psi and performs across a wide temperature range of -60 to 200 degrees F, making it reliable in cold storage environments as well as heated industrial spaces. Shore D 50 hardness gives the tube enough body to hold its routed path while remaining easy to cut and connect. It carries FDA and NSF-51 compliance, supporting food-processing and sanitary-service installations.

This tube is used in compressed-air distribution, pneumatic control lines, and general-purpose fluid transfer in both light industrial and commercial settings. Its flexible construction makes it straightforward to route around machinery, through panels, and along equipment frames. Technicians working on pneumatic tool supply lines, automation systems, and HVAC control-air circuits will find the 100-foot coil length useful for single-run installations with minimal splicing. It is compatible with Coilock Push-to-Connect Fittings and Poly-Tube Fittings, as specified by the manufacturer.

Key Features

• 192 psi maximum working pressure for standard compressed-air service
• Wide temperature rating: -60 to 200 degrees F
• FDA and NSF-51 compliant — suitable for food-processing environments
• Shore D 50 hardness provides flexibility without kinking
• 100-foot coil length minimizes field splicing on longer runs
• Compatible with Coilock Push-to-Connect Fittings and Poly-Tube Fittings

Compatibility

Designed for use with Coilock Push-to-Connect Fittings and Poly-Tube Fittings. Verify fitting bore size matches 0.375-inch OD tubing before installation.

Installation Notes

Installation is typically performed by qualified pneumatic technicians or millwrights. Depressurize and lock out the air supply before cutting or connecting tube to any live line. Use a clean, square tube cutter rather than a utility knife to ensure a proper seat in push-to-connect fittings. Route the tube away from sharp edges, moving parts, and heat sources that exceed the 200 degrees F rating.
