Coilhose Pneumatics LRM0608 Barbed Male Connector 3/8 in

Product Description

The COILHOSE PNEUMATICS LRM0608 is a barbed push-on male hose connector designed for use in compressed air and pneumatic fluid systems. Machined from brass, this fitting features a 3/8 inch barb on one end and a 1/2 inch NPT male thread on the other, allowing a direct, tool-free hose attachment to threaded ports. It is rated for a maximum working pressure of 300 psi and handles temperatures from -40 degrees F to 212 degrees F, making it suitable for a wide range of shop and industrial service conditions. HVAC technicians, plumbers, and industrial maintenance trades commonly install this type of fitting when routing pneumatic hose to equipment or control components.

This connector is intended for push-on hose assemblies where a 3/8 inch inside diameter hose must terminate at a 1/2 inch NPT threaded port. Typical applications include air compressor outlet lines, pneumatic tool drops, pressure-fed lubrication systems, and light industrial fluid transfer lines operating within the rated pressure and temperature envelope. The brass construction offers corrosion resistance and durability in both indoor shop environments and moderately demanding field conditions.

Key Features

• 3/8 inch barb accepts push-on hose for fast, secure assembly without clamps
• 1/2 inch NPT male thread connects directly to standard threaded ports and fittings
• Brass construction provides corrosion resistance and long service life
• Rated to 300 psi maximum working pressure
• Wide temperature range: -40 degrees F to 212 degrees F

Compatibility

Designed as an OEM-style replacement fitting for pneumatic and compressed air hose assemblies using 3/8 inch inside diameter push-on hose with 1/2 inch NPT ported connections.

Installation Notes

Installation is performed by qualified mechanical or HVAC technicians. Depressurize and isolate the pneumatic system completely before removing or installing any fittings. Apply thread sealant or PTFE tape to the NPT male threads per standard practice and applicable shop or facility safety procedures. Push-on hose should be fully seated over the barb to ensure a leak-free connection before returning the system to service.
