Coilhose Pneumatics 3003 Air Hose Manifold Aluminum

Product Description

The COILHOSE PNEUMATICS 3003 is an aluminum air hose manifold designed for pneumatic distribution in compressed air systems. It serves as a central junction point, allowing a single air supply line to feed multiple outlets or tools simultaneously. The aluminum construction keeps weight low while providing solid corrosion resistance in typical shop and industrial environments. This type of manifold is installed by pipefitters, pneumatic system technicians, and maintenance professionals setting up or expanding compressed air distribution lines.

The 3003 manifold is suited for light industrial, commercial, and workshop pneumatic setups where multiple air tools or lines need to be supplied from one source. It fits into both permanent plumbing installations and flexible hose-based distribution systems. The compact, lightweight design makes it practical for installations in confined spaces or on equipment panels where a larger fitting block would not be practical.

Key Features

• Aluminum construction resists corrosion and reduces overall system weight
• Functions as a multi-outlet distribution point for compressed air lines
• Compact form factor suited for tight installation spaces
• Lightweight at 0.1667 pounds, minimizing load on supporting structures

Compatibility

Designed as an OEM-style replacement or add-on accessory for standard compressed air distribution systems using compatible pneumatic hose and fitting connections.

Installation Notes

Installation should be performed by a qualified pipefitter or pneumatic systems technician. Depressurize and lock out the compressed air supply completely before installing or replacing any manifold component. Verify that all inlet and outlet connections are rated for the system operating pressure before returning the line to service. Follow applicable OSHA and ASME compressed air system guidelines during installation.
