CMC 6013 Omnidirectional Electret Condenser Microphone

Product Description

The CMC 6013 is an electret condenser microphone designed for audio signal capture. It features an omnidirectional design, allowing it to capture sound from all directions. The microphone operates at two volts direct current and has a signal-to-noise ratio of sixty decibels. It is available with either printed circuit board mount or wire lead termination.

• Omnidirectional directivity
• Operating frequency range: one hundred to twenty thousand Hz
• Analog output type

Product Highlights

This microphone is suitable for various audio applications due to its versatile capture capabilities.

Product Information

Standard Information

• Manufacturer Part Number: 6013
• Brand: CMC

Technical Specifications

• Output Type: Analog
• Directivity: Omnidirectional
• Port Location: Top
• Sensitivity (dB): -38
• Sensitivity Tolerance (dB): +/- 3
• Sensitivity Reduction (dB): -3
• Operating Voltage (Vdc): 2
• Signal to Noise Ratio (dBA): 60
• Current Consumption (µA): 150
• Output Impedance (KΩ): 2.2
• Operating Frequency (Hz): 100 ~ 20000
• Termination: Solder Pads/Wire Leads
• Shape: Round
• Dimensions LxWxH (mm): 6 x 6 x 1.3
• Dimensions LxWxH (in): 0.24 x 0.24 x 0.05
• IP Rating: No IP Rating
