Cleveland C32248 Square End Mill 4 Flute Ticn Powdered Metal

Product Description

The CLEVELAND C32248 is a square end mill designed for precision milling operations in ferrous and non-ferrous metals. It features a 0.5 inch cutting diameter, a 1.25 inch length of cut, and a 3.25 inch overall length, making it well-suited for slotting, profiling, and peripheral milling. The tool is manufactured from powdered metal, which provides a finer grain structure and greater wear resistance compared to standard high-speed steel. A titanium carbonitride (TiCN) coating adds surface hardness and reduces friction at the cutting edge, extending tool life in abrasive cutting conditions.

This end mill is intended for use in machining centers, knee mills, and CNC milling machines in job shop, production, and toolroom environments. The coarse pitch and 30-degree helix angle support efficient chip evacuation during moderate to aggressive feed rates. With a 0.5 inch shank diameter, it mounts directly to standard ER collets, end mill holders, or set-screw holders commonly found in machine shops. It is a single-end tool and is part of the PMRC series from Cleveland.

Key Features

• Powdered metal construction for improved wear resistance over standard HSS
• TiCN coating increases surface hardness and reduces built-up edge
• 4-flute, coarse pitch design supports slotting and profiling applications
• 30-degree helix angle promotes effective chip evacuation
• Right-hand cut and right-hand flute geometry for conventional milling spindles
• Single-end configuration with matched 0.5 inch cutting and shank diameter

Compatibility

Designed as an OEM-style replacement or direct-fit tooling option for standard 0.5 inch end mill holders, ER32 collet chucks, and set-screw style tool holders used in vertical and horizontal milling applications.

Installation Notes

Installation should be performed by a qualified machinist or toolroom technician. Ensure the machine spindle is fully stopped and locked out before changing tooling. Seat the shank fully into the holder to the minimum insertion depth recommended by the holder manufacturer, and verify runout with a dial indicator before beginning a cut. Follow machine tool manufacturer guidelines for feed and speed parameters appropriate to the workpiece material.
