Cleco CV-500P Air Impact Wrench 1/2 in Drive 780 Ft/lb

Product Description

The CLECO CV-500P is a pneumatic pistol-grip air impact wrench built for demanding maintenance and service applications. Rated at 780 ft/lb of torque with a 1/2 inch square drive, it delivers 8,500 RPM and 1,200 blows per minute through a continuous air supply at 90 psi. Weighing 5.5 pounds, the CV-500P is designed for extended use without excessive operator fatigue. A 1/4 inch NPT inlet and 40.5 CFM air consumption rating require a properly sized compressor and supply line. Retainer type is pin detent. This tool is installed and operated by licensed mechanics, HVAC technicians, plumbers, and industrial maintenance professionals.

The CV-500P suits a broad range of fastener removal and installation tasks in commercial and residential maintenance environments. Its pistol-grip handle provides positive control when working in tight spaces or overhead positions. Typical applications include wheel service, mechanical assembly, equipment teardown, and general industrial fastening where high torque output is needed in a compact, handheld form factor.

Key Features

• 780 ft/lb (1,085 N/m) of torque output for heavy-duty fastening
• 8,500 RPM free speed with 1,200 impacts per minute
• 1/2 inch square drive with pin detent retainer
• Pistol-grip handle for control and reduced fatigue
• Lightweight at 5.5 pounds for extended overhead or confined-space use
• 89.1 dB sound rating — hearing protection recommended during operation

Compatibility

Designed as an OEM-style pneumatic impact wrench accepting standard 1/2 inch drive impact sockets and accessories. Requires a compressed air source capable of supplying 90 psi at 40.5 CFM through a 1/4 inch NPT inlet connection.

Installation Notes

Connect the CV-500P to a properly rated air compressor using a 1/4 inch NPT fitting and a supply hose sized to meet the 40.5 CFM demand — undersized hose or fittings will reduce tool performance. Depressurize the air line and disconnect the tool from the air supply before performing any maintenance or changing accessories. Verify the pin detent retainer is fully seated before attaching sockets. Always wear appropriate PPE including eye protection and hearing protection during operation.
