Cleaver Brooks 817-05608-000 Pressure Switch Manual Reset

Product Description

The CLEAVER BROOKS 817-05608-000 is a manual-reset pressure switch used in commercial and industrial boiler systems to monitor gas or air pressure and interrupt operation when pressure drops below a set point. The switch features an adjustable range of 1 to 20 inches water column (WC), giving technicians the flexibility to dial in the trip point to match system requirements. It is configured to break the circuit on a fall in pressure, which is the standard safety action for proving burner airflow or gas pressure in fired equipment. Installation and commissioning are typically performed by licensed boiler technicians or commercial HVAC service contractors.

This pressure switch is suited for commercial and industrial boiler applications where proven pressure monitoring is required as part of the burner safety circuit. It cross-references to the Honeywell C6097A3012, making it applicable wherever that Honeywell part is specified. The manual-reset design means the switch must be physically reset after a lockout condition, which is standard practice on safety-critical combustion systems to ensure a technician reviews the fault before the burner is allowed to restart.

Key Features

• Adjustable pressure range of 1 to 20 inches WC to accommodate varying system setpoints
• Breaks circuit on pressure fall for reliable safety shutoff in burner proving applications
• Manual reset required after lockout, preventing automatic restart without technician intervention
• Cross-references Honeywell C6097A3012 for drop-in replacement use
• Designed for commercial and industrial boiler burner safety circuits

Compatibility

This switch cross-references to the Honeywell C6097A3012 and is intended as a replacement in systems where that part is specified. It is designed for use in commercial and industrial boiler burner control circuits requiring a manual-reset, break-on-fall pressure switch in the 1 to 20 inches WC range.

Installation Notes

Installation should be performed by a licensed boiler technician or qualified combustion service contractor. Before servicing, shut off gas supply and disconnect power to the burner control panel in accordance with applicable codes, including NFPA 54 and local authority having jurisdiction requirements. Verify the pressure sensing port connection is leak-free before restoring system power. After any lockout event, investigate and resolve the root cause of the pressure fault before manually resetting the switch and returning the burner to service.

Technical Specifications

• Adjusting Range: 1 to 20 inches WC
• Action: Breaks on fall
• Reset Type: Manual reset
• Cross-Reference Part Number: Honeywell C6097A3012

Standard Information

• Brand: CLEAVER BROOKS
• Manufacturer Part Number: 817-05608-000
