Chicago-Latrobe 46745 Heavy Duty Jobber Length Drill Bit #75 Drill - Wire 0.021 in Drill - Decimal Inch

Product Description

The Chicago-Latrobe 46745 is a heavy-duty jobber length drill bit designed for tough applications. It features a #75 wire drill size and a decimal inch measurement of zero point zero two one inches. The drill has a 135-degree point angle and is made from M42 HSS-Co eight percent cutting edge material. With an overall length of one inch and a cutting depth of five times the diameter, this drill bit is suitable for drilling in alloy steel, stainless steel, titanium, and tool steel.

• Designed for tough, high-tensile materials
• 135-degree split point for easy penetration
• Features right spiral flutes and superior cutting capability

Product Highlights

Chicago-Latrobe 46745 is ideal for various drilling tasks in hard materials under extreme conditions. Its construction allows it to handle high-tensile and work-hardening materials effectively.

Product Information

Standard Information

• Brand: Chicago-Latrobe
• Type: Heavy Duty

Technical Specifications

• Applicable Materials: Alloy Steel, Stainless Steel, Titanium, Tool Steel
• Cutting Depth: 5XD
• Cutting Direction: Right Hand
• Cutting Edge Material: M42 HSS-Co 8%
• Drill Diameter Measurement System: Imperial
• Flute Length: 1/4 in
• Flute Type: Right Spiral
• Number of Flutes: 2
• Overall Length: 1 in
• Point Type: Split
• Series: 550
• Shank Size: 0.021 in Dia x 0.75 in L
• Shank Type: Straight
• Drill Size - Wire: #75
• Drill Size - Decimal Inch: 0.021 in
• Point Angle: 135 deg
• Finish: Straw Oxide
• Through Coolant: No
