Chicago Die Casting 200-A-3/4 V-Belt Pulley

Product Description

The Chicago Die Casting 200-A-3/4 is a V-belt pulley specifically made for A belts and compatible with 4L or half by eleven thirty-second belts. It has a three-quarter inch bore and an outer diameter of two inches. This pulley is made from zinc and is equipped with slotted headless set screws.

• Compatible with A belts and 4L or half by eleven thirty-second belts.
• Features a three-quarter inch bore.
• Constructed from durable zinc material.

Product Highlights

This pulley is ideal for a variety of applications requiring reliable functionality and compatibility with standard belt sizes.

Product Information

Standard Information

• Brand: Chicago Die Casting
• MPN: 200-A-3/4

Technical Specifications

• Type: V-Belt Pulley
• Outside Diameter: 2 inches
• Bore Size: 3/4 inches
• Face Width: 11/16 inches
• Pitch Diameter: 1-3/4 inches
• Keyway Size: 3/16 x 3/32 inches
• Material: Zinc
• Width: 1-1/16 inches
• Belt Size: 1/2 inch W x 11/32 inch Thick
• Includes: Hollow Head Set Screws
