CHEMTROL NL9600D T-580-A 2-Piece Ball Valve 2 in Nominal FNPT

Product Description

The CHEMTROL NL9600D T-580-A is a two-piece ball valve ideal for controlling gas or water flows. It features threaded end connections for simple installation and operation with a quarter-turn design. This valve is suitable for both commercial and residential applications, making it a versatile choice for various plumbing needs.

• 2 in nominal size with FNPT end style
• Pressure rating up to 400 psi
• Polished chrome brass ball for durability

Product Highlights

This ball valve offers safe and reliable operation. The blowout-proof stem enhances safety during use.

Product Information

Standard Information

• Brand: CHEMTROL
• Manufacturer: NIBCO Inc.

Technical Specifications

• Actuator Type: Standard Lever Handle
• Ball Material: Polished Chrome Brass
• Body Material: Brass
• End Style: FNPT
• Inlet to Outlet Length: 3.73 inches
• Media: Gas/Water
• Nominal Size: 2 inches
• Orifice Size: 1.46 inches
• Pressure Rating: 400 psi
• Softgoods Material: Fluorocarbon/PTFE
• Top to Inlet Center: 2.95 inches
• Trim Material: Brass
• Stem Type: 2-Piece
