CHEMTROL NL958H6 T-585-70-66-HC 2-Piece Ball Valve 1/2 x 3/4 in NPT x Hose

Product Description

The CHEMTROL NL958H6 T-585-70-66-HC is a two-piece ball valve designed for commercial and light industrial applications. This valve features a bronze body and is suitable for use with garden hose connections for drainage purposes. The valve operates with a quarter-turn (90 degrees) mechanism for easy opening and closing, providing bubble-tight shutoff at a maximum pressure of 600 psi.

• Designed for garden hose connections
• Quarter-turn operation for ease of use
• Bubble-tight shutoff at 600 psi

Product Highlights

The CHEMTROL ball valve is a versatile choice in a range of applications, made with durable materials to withstand high pressure and temperature.

Product Information

Standard Information

• Manufacturer: NIBCO Inc.
• Domestic/Import: Domestic

Technical Specifications

• Actuator Type: Standard Lever Handle
• Ball Material: 316 Stainless Steel
• Body Material: Bronze
• End Style: NPT x Hose
• Inlet to Outlet Length: 2.84 inches
• Media: Water
• Nominal Size: 1/2 x 3/4 inches
• Orifice Size: 1/2 inches
• Port Type: Full
• Pressure Rating: 600 psi
• Series: T-585-70-66-HC
• Softgoods Material: PTFE
• Temperature Rating: 400 degrees F
• Top to Inlet Center: 1.88 inches
• Trim Material: 316 Stainless Steel
• Stem Type: 2-Piece
