CHEMTROL NJ93H2A S-595-Y-66-LF 3-Piece Ball Valve 1 in Nominal

Product Description

The CHEMTROL NJ93H2A is a three-piece ball valve designed for reliable use in plumbing systems. Made from silicon bronze, it features solder ends that simplify installation. This valve is ideal for both commercial and residential applications, especially those involving drinking water.

• Lead-free construction for safe water delivery
• Bubble-tight shut-off at 600 psi
• Standard lever actuator for easy operation

Product Highlights

This valve delivers strong performance with its full port design, making it suitable for high-pressure applications.

Product Information

Standard Information

• Brand: CHEMTROL
• Manufacturer: NIBCO Inc.

Technical Specifications

• Actuator Type: Standard Lever
• Ball Material: Stainless Steel
• Body Material: Silicon Bronze
• End Style: Solder
• Inlet to Outlet Length: 3.66 in
• Media: Water
• Nominal Size: 1 in
• Orifice Size: 1 in
• Port Type: Full
• Pressure Rating: 600 psi
• Series: S-595-Y-66-LF
• Softgoods Material: PTFE/FKM
• Temperature Rating: 300 deg F
• Top to Inlet Center: 2-1/4 in
• Trim Material: Stainless Steel
• Stem Type: 3-Piece
