CHEMTROL NF84HC6 NIBCO PC-585-70-66 2-Piece Ball Valve 1/2 in Nominal

Product Description

The CHEMTROL NF84HC6 is a 2-piece ball valve made from bronze. This valve features press-to-connect end connections designed for quick installation. The EPDM O-rings provide a watertight seal when using a press-fit tool.

• Compatible with NIBCO Press System
• Domestic manufacturing with quality assurance
• Rated for 250 psi pressure and temperatures up to 250 degrees Fahrenheit

Product Highlights

This valve is suitable for various plumbing applications, offering reliability and efficiency. It is designed for use in residential and industrial piping systems.

Product Information

Standard Information

• Brand: CHEMTROL
• Manufacturer: NIBCO Inc.

Technical Specifications

• Actuator Type: Standard Lever Handle
• Ball Material: Stainless Steel
• Body Material: Bronze
• Dimensions: 6 inches Length
• End Style: Female Press
• Inlet to Outlet Length: 4.15 inches
• Nominal Size: 1/2 inch
• Orifice Size: 1/2 inch
• Pressure Rating: 250 psi
• Series: PC-585-70-66
• Softgoods Material: EPDM/PTFE
• Temperature Rating: 250 degrees Fahrenheit
• Top to Inlet Center: 1.9 inches
• Trim Material: 316 Stainless Steel
• Stem Type: 2-Piece
