Charlotte Pipe PVC-504-12X12X10 Dwv Combo Wye Fitting

Product Description

The CHARLOTTE PIPE PVC-504-12X12X10 is a two-piece PVC combination wye and 1/8 bend fitting designed for drain, waste, and vent (DWV) applications. It features a 12 x 12 x 10 inch configuration and is built for non-pressure, gravity-fed waste elimination systems. Rated for service up to 140 degrees F, this fitting is made from PVC, which keeps weight low and simplifies handling on the job. Licensed plumbers and pipefitters install this type of fitting where a branch connection and a directional change are needed in a single assembly, reducing the number of joints in the run.

This fitting is suited for residential and commercial DWV piping systems where gravity drainage is the design basis. The combo wye and 1/8 bend configuration is a standard choice for main drain lines and stack connections. It accepts solvent cement joining, the most common installation method in PVC DWV work, and is also compatible with threading, flanging, and roll-grooved joining methods depending on system design. Its large 12-inch main line size makes it appropriate for high-flow drain stacks and building drain applications.

Key Features

• Two-piece combo wye and 1/8 bend in a single fitting reduces joint count and simplifies layout
• 12 x 12 x 10 inch configuration suits large-diameter main drain and stack installations
• Rated for non-pressure, gravity-fed DWV systems up to 140 degrees F
• Compatible with solvent cement, threading, flanging, and roll-grooved joining
• Lightweight PVC construction requires no special cutting tools
• Manufactured in the USA

Compatibility

Designed as an OEM-style replacement and standard-use fitting for PVC DWV piping systems operating under non-pressure, gravity-fed conditions.

Installation Notes

Installation should be performed by a licensed plumber in accordance with the International Plumbing Code (IPC) and applicable local codes. Shut off the water supply and ensure the system is fully depressurized before cutting into an existing drain line. Solvent cement joints require proper primer and cement application with adequate cure time before system use. Do not install in pressurized or high-temperature systems exceeding the fitting's rated service temperature.

Technical Specifications

• Material: PVC
• Fitting Type: Combination Wye and 1/8 Bend, Two-Piece
• Application: Drain, Waste, and Vent (DWV)
• System Type: Non-Pressure, Gravity-Fed
• Max Temperature: 140 degrees F
• Size Configuration: 12 x 12 x 10 inches
• Joining Methods: Solvent Cement, Threading, Flanging, Roll-Grooved
• Country of Origin: USA
• UPC: 611942101740

Standard Information

• Brand: CHARLOTTE PIPE
• Manufacturer Part Number: PVC-504-12X12X10
