Charlotte Pipe Pvc 4007 3/4 X 10 Schedule 40 Pvc Pipe

Product Description

The CHARLOTTE PIPE PVC 4007 3/4 X 10 is a Schedule 40 PVC pressure and DWV pipe in a 3/4-inch nominal size, supplied in 10-foot plain-end lengths. Manufactured from PVC conforming to ASTM D1784 and D1785, this pipe carries a pressure rating of 480 psi at 73 degrees F and a temperature rating of 140 degrees F. The white finish, 0.113-inch wall thickness, and plain-end connections make it straightforward to cut, prime, and solvent-cement into new or replacement installations. It is made in the USA and backed by a 5-year limited warranty. Plumbers and pipefitters rely on it for its high tensile strength, impact resistance, and better sound-deadening performance compared to DWV foam-core PVC pipe.

This pipe is suited for residential and light commercial plumbing systems where Schedule 40 PVC is the specified material. Typical applications include drain, waste, and vent (DWV) runs as well as low-pressure water distribution lines. Its plain-end configuration accepts standard Schedule 40 solvent-weld fittings. For any pressure application, sharply angled pressure fittings must be used at directional changes. At 21.1 pounds per 100 feet, the pipe is light enough for one-person handling during rough-in work in walls, floors, and crawl spaces.

Key Features

• 480 psi pressure rating at 73 degrees F for reliable performance in pressure lines
• 0.113-inch wall thickness meeting ASTM D1784 and D1785 material specifications
• NSF 14/61 listed, confirming suitability for potable water contact
• Better sound-deadening characteristics than PVC Schedule 40 DWV foam-core pipe
• Plain-end x plain-end connections accept standard solvent-weld Schedule 40 fittings
• Made in the USA with a 5-year limited warranty

Compatibility

Designed as an OEM-style replacement and new-construction pipe for residential and commercial Schedule 40 PVC plumbing systems; accepts standard Schedule 40 plain-end solvent-weld fittings sized for 3/4-inch nominal pipe.

Installation Notes

Installation must be performed by a licensed plumber in accordance with applicable local plumbing codes and IPC requirements. Always shut off the water supply and depressurize the line before cutting into an existing system. Primer and solvent cement are required for all joints; do not use this pipe with threaded or compression fittings without an appropriate adapter. For pressure applications, use sharply angled pressure fittings at all directional changes to maintain rating integrity.

Technical Specifications

• Nominal Pipe Size: 3/4 inch
• Schedule: 40
• Length: 10 feet
• Wall Thickness: 0.113 inches
• Pressure Rating: 480 psi at 73 degrees F
• Temperature Rating: 140 degrees F
• End Connection: Plain End x Plain End
• Material: PVC
• Material Specification: ASTM D1784/D1785
• Applicable Standard: NSF 14/61
• Process: Injection Molded
• Finish: White
• Application: DWV and Pressure
• Weight: 21.1 pounds per 100 feet
• Country of Origin: USA
• Warranty: 5-Year Limited

Standard Information

• Brand: CHARLOTTE PIPE
• Manufacturer Part Number: PVC 4007 3/4 X 10
