Charlotte Pipe PVC-323-4IN Pvc Dwv 45 Degree Street Elbow 4 in

Product Description

The CHARLOTTE PIPE PVC-323-4IN is a 4-inch PVC DWV 45-degree street elbow designed for drain, waste, and vent piping systems. This fitting directs flow at a 45-degree angle and is configured as a street pattern, meaning one end accepts a spigot and the other a socket for direct in-line connections without an additional coupling. It is rated for non-pressure, gravity-fed waste elimination systems in applications where temperatures will not exceed 140 degrees F. Licensed plumbers and pipefitters install this fitting in residential and commercial DWV rough-in work.

This fitting is suited for 4-inch DWV drain, waste, and vent piping in residential and light commercial construction. Typical applications include horizontal drain offsets, branch connections in soil stacks, and vent routing where a gradual directional change is needed. The street configuration allows the spigot end to insert directly into the hub of an adjoining fitting, reducing the number of components required at a connection point. All Charlotte Pipe PVC fittings are manufactured in the USA.

Key Features

• 45-degree street elbow pattern allows direct spigot-to-hub connection without an extra coupling
• Rated for non-pressure gravity-fed drain, waste, and vent systems
• Maximum service temperature of 140 degrees F
• Compatible with solvent cement joining for a leak-free, permanent bond
• Lightweight PVC construction requires no special cutting tools
• Manufactured in the USA

Compatibility

Designed as an OEM-style replacement or new-installation fitting for 4-inch PVC DWV piping systems operating under non-pressure, gravity-flow conditions.

Installation Notes

Installation should be performed by a licensed plumber in accordance with applicable local plumbing codes and the International Plumbing Code (IPC). Shut off water supply and verify the drain line is clear before cutting into an existing system. Solvent cement joining requires proper primer and cement rated for PVC DWV applications; follow cement manufacturer dwell and cure times before restoring flow. Do not use this fitting in pressurized supply lines or in systems where operating temperatures exceed 140 degrees F.

Technical Specifications

• Pipe Size: 4 inches
• Fitting Type: 45-Degree Street Elbow (1/8 Bend)
• Material: PVC
• System Type: DWV (Drain, Waste, Vent)
• Max Temperature: 140 degrees F
• Joining Method: Solvent Cement, Threading, Flanging, Roll-Groove
• Pressure Rating: Non-Pressure (Gravity-Fed Only)
• Country of Origin: USA
• UPC: 611942034116

Standard Information

• Brand: CHARLOTTE PIPE
• Manufacturer Part Number: PVC-323-4IN
